The MIIVII BRD601 THOR is specifically tailored for the embodied intelligence developer market. This product is designed to meet the R & D needs of humanoid robot software algorithm researchers, manufacturers, and embodied intelligence companies, providing more powerful and user - friendly hardware support.
The BRD601 THOR, with its compact size, offers a rich variety of interface options such as RS485, RS232, CAN, and GMSL, greatly improving development efficiency.
The BRD601 THOR provides a computing power of up to 2070 FP4 TFLOPS/1035 FP8 TFLOPS, which can well meet the visual computing needs of humanoid robots.
Microsecond-level time synchronization
8×GMSL2 video input interfaces
Operating temperature from -25℃ to 70℃
| Processor | NVIDIA® Jetson T5000™ |
| Performance | 2070 TFLOPS (FP4-Sparse) |
| GPU | NVIDIA Jetson T5000 Module： |
| CPU | 14-core Arm® Neoverse®-V3AE 64-bit CPU | 1 MB L2 cache per core |
| Memory | 128 GB / 64 GB 256-bit LPDDR5X 273 GB/s |
| Video Accelerator | PVA v3.0 |
| Storage | External Storage (NVMe via PCle) |
| Video Encoder | 6 x 4Kp60 (H.265) | 12 x 4Kp30 (H.265) |24 x 1080p60 (H.265) 50 x 1080p30 (H.265) | 48 x 1080p30 (H.264) | 6 x 4Kp60 (H.264) |
| Video Decoder | 4 x 8Kp30 (H.265) | 10 x 4Kp60 (H.265) | 22 x 4Kp30 (H.265) | 46 x 1080p60 (H.265) 82 x 1080p30 (H.264) | 92 x 1080p30 (H.265) | 4 x 4Kp60 (H.264) |
| GMSL Camera | 8× GMSL2 Mini FAKRA TYPE C (10V,Transmission distance up to 15 meters, GMSL2 compatible with GMSL1) |
| I/O | 2 × 2.5G RJ45 (PTP、EtherCAT) | 1 x QSFP28 (4 x 25GbE) | 1 x HDMI 2.0 (TYPE A) 1 x USB 3.0 (TYPE C) | 1 x USB 3.0 (TYPE C with flash function) | 4 x CAN FD | 3 x DI 4 x DO (High Side Driver) | 2 x DO (Low Side Driver) | 6 x CAN | 1 x RS232 |
| Expansion Interface | 1× M.2 M Key (2280，PCIE x 4) | 1 x M.2 B Key | 1× Nano SIM | 1 x M.2 E Key |
| Input Voltage | 9V-36V DC |
| Dimensions | 185mm x 105mm x 80mm |
Humanoid Robot
Research Field
Autonomous Driving Algorithm Research
Mobile Robot Control Algorithm
